1-Durability of electric abrasion
2-Low and stable connect resistance
3-High stability when working
4-Prevent oxidized when exposure to the air
5-Less and even electrolytic corrosion
Electrical Contact Welding are increasingly dominating the market for medium and high current contact relays because of their low arc erosion. Besides the base oxide SnO2 embedded in the Ag matrix, these materials may or may- not contain additives like Bi2O3, CuO, In2O3 in a combination of varying amounts not exceeding 2%. The Brazing Electrical Contacts are manufactured by powder metallurgy (powder blending, compaction and sintering) followed by extrusion/ drawing/ rolling to the final dimensions.
The Contact Tip Welding resistance value of the silver contacts under different pressures. As the pressure increases, the contact area between the Welding Electrical Contact and the silver plate continues to increase, and the contact resistance between the silver contacts should gradually decrease. The effect of pressure on the resistance of Electrical Contact Resistance Brazing: As the pressure continues to increase, the resistance value decreases in a fast and then slow manner: when the pressure increases from 10 N to 200 N, the resistance decreases linearly, and then the decline slows down. When the pressure reaches 1 kN or more, it gradually stabilizes, and when the pressure is 1.4 to 2.0 kN, there is basically no change in the Low Voltage Electrical Contacts resistance. Therefore, in order to obtain a more accurate Brazed Electrical Contacts resistance value, it should be measured at a pressure of >1.5 kN. Comparing the steady-state resistance values of Brazed Electrical Contacts with different brazing rates, it can be found that the resistance decreases as the brazing rate of Contacts Metals Welding increases, that is, the larger the soldered area, the better the conductivity of the silver contacts.
Alloy oxide contact products are widely used in low-voltage electrical appliances, and the Welding Electrical Contact main uses are:
1-Silver tin oxide series Resistance welding Contacts:
The Brazing Electrical Contacts are suitable for medium and large capacity AC contactors (such as CJ20, CJ40, 3TF series, etc.), high-power AC switches (above 50kW), DC contactors, AC and DC power relays, and automotive electrical appliances And on the low-voltage circuit breaker of small and medium capacity.
2-Silver zinc oxide series Silver Contact Welding:
Electrical Contact Welding are mainly used in small and medium capacity low voltage circuit breakers with rated current within 200A (such as DZ15 series molded case circuit breakers, especially universal circuit breakers), as well as power protection switches, leakage protection switches, AC relays, DZ15L series leakage current Circuit breakers, etc., some large-capacity switches also use AgZnO materials Contacts Metals Welding, such as ME universal circuit breakers.
3-Silver cadmium oxide series Welded Electrical Contact:
The Welded Contacts widely used in medium and large capacity relays, contactors, AC and DC switches and medium and small capacity circuit breakers, especially suitable for medium and large capacity AC contactors. For the production of silver metal oxide contact products Contact Welding, the existing production of intermediate frequency melting furnaces, hot rolling mills, finishing mills, automatic stamping machines, oxidation furnaces, isostatic presses, extruders, atomic absorption spectrometers, metallographic microscopes, etc., 150 sets of testing equipment can be developed and produced according to the specific requirements of users, with an annual production capacity of 320 tons.
