1- Products Name: Busbar with Pins for PV Solar Circuit Breaker
2- Base Material Standard:
GB : T2Y2 Copper
DIN: E-Cu58 (Number: 2.0065)
EN: Cu-ETP ( Number: CW004A)
ISO: Cu-ETP
UNS: C11000
JIS: C1100
BS: C101
Purity ≥99.99% Copper, Conductivity %IACS≥97, Hardness 80~110HV, Tensile Strength 245-345MPa, other material also can be customized.
3-Surface Treatments:
(3.1) Silver plating
(3.2) Tin plating
(3.3) Nickel plating
(3.4) Ultrasonic cleaning
Normally plated thickness is 3μm to 12μm, but all upon customers' request.
4- Insulation Options:
(4.1) PET insulation paper (brands USA GTS, GERMANY KREMPEL, etc with white or milky white colors)
(4.2) PVC dipping (orange and green are the most popular colors)
(4.3) Epoxy powder coating (orange, green and grey are the most popular colors)
(4.4) PE heat shrink tube (orange, green, black, red are yellow are the most popular colors)
(4.5) PA66 plastic housing (white, grey etc are the most popular colors)
Flame Retardant / Fire Resistance: UL94-V-0 or upon you request;
Operating Temperature: -45ºC to +150 ºC
5- Copper Busbar Resistance: ≤0.00001Ω
6- Copper Busbar load voltage 3500VDC to 5000VDC and current 100A to 2000A
7- Copper Busbar Assembly Fixtures: USA PEM stainless nuts, studs, standoffs, screws, etc
8- Free Samples:1-10pcs is allowed
9- Lead Time:Orders 7-10days,Samples 10-20days(including the tooling/die production of Copper Stamped Part);
10- Packing: pearl cotton/blister box inside and carton/pallet outside
11- Certifications: ISO9001, IATF16949, RoHS, REACH, etc.
12- Production Capacity: 50,000,000 pcs/month
13- Applications: film capacitors for new energy electric vehicles and hybrid vehicles, new energy vehicle battery packs, new energy photovoltaic energy storage, power appliances, distribution cabinets, rail transit, cloud server uninterruptible power supplies and other power systems.
A busbar with pins in the context of a PV (photovoltaic) solar circuit breaker is likely used for electrical connections within a solar power system. Here's how it may be applied:
1.Connection to Circuit Breaker:
The copper busbar with pins is likely designed to connect to a PV solar circuit breaker. This busbar connection is crucial for the safe and efficient functioning of the solar power system. It provides a secure electrical connection between the solar panels and the circuit breaker.
2.Interconnecting Solar Panels:
In a solar power system, multiple solar panels are often connected in series or parallel. The PP Plastic Insulation Busbar can be used to interconnect these panels, allowing for a streamlined and organized electrical connection.
3.Distribution of Electrical Power:
3&4 Phases Pin Type Insulated Busbars are commonly used for distributing electrical power within a system. In the context of a PV solar circuit breaker, the busbar with pins may facilitate the distribution of electrical power from the solar panels to the circuit breaker, ensuring that the power generated is properly managed and controlled.
4.Modular System Design:
Solar power systems are often designed with modular components. The Three Phase Fork Style Insulated Busbar can play a role in this modular design, allowing for easy installation, maintenance, and expansion of the solar power system.
5.Safety and Efficiency:
Proper electrical connections are crucial for the safety and efficiency of a solar power system. The Module Insulated Prong Busbar is likely designed to ensure reliable and low-resistance connections, reducing the risk of electrical issues and optimizing the performance of the solar circuit breaker.
It's important to note that the specific application may vary based on the design and specifications of the PV solar circuit breaker and the overall solar power system. If you have a particular product or system in mind, referring to the manufacturer's documentation or specifications would provide detailed information on the application of the Insulated Busbar Pin Type in that specific context.
