1- Products Name: Tin-Plated Bus Bar with Nut for UPS
2- Base Material Standard:
GB : T2Y2 Copper
DIN: E-Cu58 (Number: 2.0065)
EN: Cu-ETP ( Number: CW004A)
ISO: Cu-ETP
UNS: C11000
JIS: C1100
BS: C101
Purity ≥99.99% Copper, Conductivity %IACS≥97, Hardness 80~110HV, Tensile Strength 245-345MPa, other material also can be customized.
3-Surface Treatments:
(3.1) Silver plating
(3.2) Tin plating
(3.3) Nickel plating
(3.4) Ultrasonic cleaning
Normally plated thickness is 3μm to 12μm, but all upon customers' request.
4- Insulation Options:
(4.1) PET insulation paper (brands USA GTS, GERMANY KREMPEL, etc with white or milky white colors)
(4.2) PVC dipping (orange and green are the most popular colors)
(4.3) Epoxy powder coating (orange, green and grey are the most popular colors)
(4.4) PE heat shrink tube (orange, green, black, red are yellow are the most popular colors)
Flame Retardant / Fire Resistance: UL94-V-0 or upon you request;
Operating Temperature: -45ºC to +150 ºC
5- Copper Busbar Resistance: ≤0.00001Ω
6- Copper Busbar load voltage 3500VDC to 5000VDC and current 100A to 2000A
7- Copper Busbar Assembly Fixtures: USA PEM stainless nuts, studs, standoffs, screws, etc
8- Free Samples:1-10pcs is allowed
9- Lead Time:Orders 7-10days,Samples 10-20days(including the tooling/die production of Copper Stamped Part);
10- Packing: pearl cotton/blister box inside and carton/pallet outside
11- Certifications: ISO9001, IATF16949, RoHS, REACH, etc.
12- Production Capacity: 50,000,000 pcs/month
13- Applications: film capacitors for new energy electric vehicles and hybrid vehicles, new energy vehicle battery packs, new energy photovoltaic energy storage, power appliances, distribution cabinets, rail transit, cloud server uninterruptible power supplies and other power systems.
A tin-plated bus bar with a nut for Uninterruptible Power Supply (UPS) applications involves the use of a tin-plated bus bar, often accompanied by a nut for secure connections within the UPS system. Here's an overview of the components and considerations related to tin-plated bus bars with nuts for UPS applications:
1- Copper Bus Bar Material:
Copper: Bus bars are typically made from highly conductive materials such as copper or aluminum, providing efficient electrical conductivity.
2- Copper Busbar Tin Plating:
Corrosion Resistance: Tin plating is applied to the bus bar to enhance corrosion resistance. This is particularly important in UPS systems, where exposure to various environmental conditions may occur.
Low Contact Resistance: Tin plating helps reduce contact resistance, ensuring a reliable and efficient flow of electrical current.
3- Copper Busbar Nut Attachment:
Material: The nut is commonly made of a durable material, such as stainless steel, to provide mechanical strength and corrosion resistance.
Threaded Connection: The nut is threaded onto the bus bar, creating a secure connection. This threaded connection facilitates easy installation and maintenance.
4- Copper Busbar Electrical Conductivity:
Maintaining Conductivity: Tin plating on the bus bar ensures that the electrical conductivity of the system is maintained. It also helps prevent oxidation, which could affect the electrical performance.
5- Copper Busbar Corrosion Resistance:
Protection Against Corrosion: Tin plating and the use of corrosion-resistant nuts protect the bus bar and the connection points from corrosion. This is vital for the long-term reliability of the UPS system.
6- Copper Busbar Threaded Connection:
Secure Fastening: The threaded connection with the nut provides a secure fastening method, reducing the risk of loose connections, which is critical in UPS applications to ensure stable power supply.
7- Copper Busbar Ease of Installation:
Simple Assembly: The threaded nut allows for a straightforward assembly process, simplifying installation and maintenance procedures in the UPS system.
8- Copper Busbar Compatibility with UPS Components:
Standard Sizes and Configurations: Bus bars and nuts are often manufactured in standard sizes and configurations to ensure compatibility with various UPS components and systems.
9- Copper Busbar Heat Dissipation:
Efficient Heat Dissipation: The materials used in the bus bars, combined with the tin plating, contribute to efficient heat dissipation, which is essential in UPS applications where thermal management is crucial.
10- Copper Busbar Reliability and Longevity:
Durable Construction: The combination of tin plating and high-quality nuts contributes to the overall reliability and longevity of the connections in the UPS system.
11- Copper Busbar Compliance with Standards:
Meeting Electrical Standards: Manufacturers often adhere to electrical and safety standards to ensure that the tin-plated bus bars and nuts meet industry requirements.
Tin-plated bus bars with nuts are employed in UPS systems to provide efficient, reliable, and corrosion-resistant electrical connections. The combination of materials, plating, and threaded connections ensures the performance and longevity of the electrical components within the UPS application.
